VSD 4720 420 Kv Fpv UAV TSAV



Qhov no 4720 txhuam lub cev muaj zog ENLANS kev lag luam siab thiab ua kom tiav rau cov khoom siv hluav taws xob hauv nruab nrab, thiab tsim nyog rau ntau lub davhlau muaj teeb meem.



4720 420 Kv Lub Cev Tsav Tsheb

Voltage (lipo)	Lub Hwj Chim (Max)	Tam sim no (max)	Kv	Tsis muaj kev thauj khoom tam sim no (10V)	Sab nraud txoj kab uas hla	Tus naj npawb ntawm cov ncej ncej
6S ~ 8S	3037	99.7	420	＜2.0A	6mm	12N/14P
Interfahase Sab Hauv Kev Tawm	core loj	Kev muaj zog loj	Chav Kawm Kub	Silicone Hlau	Lub cev muaj zog phaus (suav nrog hlau)
25mΩ	φ47mm × 20mm	φ54.7mm × 69.8mm	H	14AWG / 800mm	336±3



Customize Xav Tau	Yog / tsis yog
Xovtooj ntev	Tau
Cov xov hlau	Tau
Kv	Tau
Kev muaj zog loj	Tsis muaj
Tus Hlau Mounting Qhov	Tsis muaj
Rotor Xim	Tau
Stator Xim	Tau
Lub plhaub Xim	Tau



VSD 4720 Tsav Tsim



Engineering Zoo

Kev sib xyaw ua ke ntawm kev sib nqus siab ceev stator thiab tsis tshua muaj lub ntiaj teb ruaj khov Magnet rotor ua tiav lub zog pib thiab nrawm nrawm;



12N146P ncej ib pawg qauv, nqa lub zog du thiab kho kom meej;



H-chav rwb thaiv tsev Qib winding system txhawb nqa kev ua haujlwm tsis tu ncua nyob rau kev thauj khoom siab thiab muaj kev ntseeg tau ntau dua;



14awg Ntev Hlau Tsim, Yooj Yim rau Nruab Rau Loj



Xaiv cov kabmob cov kabmob thiab kev sib npaug sib npaug kev hloov kho kom dav ruaj khov thiab lub neej sib xws .



Qhov no 4720 tsav 420kv no tsis tsuas yog excors cov tsis muaj zog, tab sis kuj yog cov tshuab kev sib xyaw ua ke xws li kev tsim hluav taws xob ua haujlwm tau tsim rau "} {{4 4}}



Txhawm rau txhawm rau kev ua tau zoo ntawm 4720 lub cev muaj zog 420kv nyob rau hauv cov xwm txheej sib tw, peb tau sim, hluav taws xob, ua haujlwm, thiab lwm yam}., simulating lub nra hloov hauv davhlau tiag tiag {13 {}



Tsis muaj .	Kuaj Hluav Taws Xob Hluav Taws Xob	Tus kiv kom lub nkoj mus tom ntej	Qhov tsuj roj	Voltage (v)	Tam sim no (a)	Thrust (G)	Ceev (RPM)	Hwjchim (W)	Efficiency (g / w)	Qho so
1	80A Esc	HQ15 XXX7X3	30%	23.96	3.2	648	2932	77.2	8.4	76
			40%	23.94	6.1	1119	3829	147.1	7.61
			50%	23.91	11.5	1769	4798	273.9	6.46
			60%	23.86	18.9	2531	5705	450.7	5.62
			70%	23.79	28.8	3432	6576	685.2	5.01
			80%	23.69	42.3	4487	7441	1002.7	4.48
			90%	23.61	58	5514	8202	1368.7	4.03
			100%	23.46	79.8	6750	8963	1872.4	3.61
2	100AC	Gf13x9x3	30%	31.96	4	815	3824	127.7	6.38	92
			40%	31.94	7.9	1426	5022	253.1	5.64
			50%	31.89	14.8	2213	6278	470.7	4.70
			60%	31.84	24.4	3159	7444	776.7	4.07
			70%	31.74	39.7	4313	8703	1261.4	3.42
			80%	31.61	57.6	5469	9770	1820.1	3.00
			90%	31.48	79.0	6580	10711	2488.5	2.64
			100%	30.46	99.7	7232	11284	3037.4	2.38
Lub cev muaj zog kub yog qhov kub uas lub cev muaj zog khiav rau {% throttle (nws tsis tuaj yeem muab piv rau cov ntaub ntawv los ntawm cov ntaub ntawv tsis yog peb xeem)



Tsis tas li ntawd, lub cev muaj zog 4720 tseem tuaj yeem siv nrog 17x5. 8 lossis 16x6.5 Carbon Fiber propellers, txuas ntxiv mus rau hovering thiab muaj zog cua tsis kam.



Nrog lub zog siab heev tso zis txog li 3037w thiab lub zog tshaj plaws ntawm 7 {}}}} 2k braticibless muaj peev xwm, thiab haum rau ntau hom nruab nrab thiab loj UAV tshuab.



1. hnyav-ntim kev yees duab drone ({} Axis / {{achis platform)

Lub cev muaj zog 4720 tuaj yeem muab cov khoom siv txuas mus ntxiv thiab cov khoom siv davhlau-{} Nws-hniav ua haujlwm ntawm kev ua haujlwm siab thiab cov khoom lag luam qis .



2.} Cov Drones Drones: Soj ntsuam, kev nyab xeeb thiab cog cog qoob loo

Nrog 8s-voltage fais fab mov thiab 100a esc, lub cev muaj zog no tuaj yeem ua tiav kev sib tw ua kom zoo, lossis cov lus teb muaj kev ruaj ntseg zoo li ntawm cov neeg muaj kev ruaj ntseg thiab cov lus teb siab nrawm nrawm ceev {}}



3. Kev Tshawb Fawb Ntev} Kev Ntsuam Xyuas thiab VTOL thiab VTOL ntsug coj-tawm thiab tsaws platform

Thaum siv 15-17 nti} nti nti, lub cev muaj zog ua kom muaj zog ruaj khov, thiab siv cov hluav taws xob nrawm nrawm nrawm



{{0 {}} logistics thiab done xa tuaj

Rau logistics ntau-rotor platforms uas yuav tsum tau nqa 3 ~ 5kg ntawm cov ntaub ntawv, 4720 lub cev muaj zog nrog cov roj teeb muaj peev xwm saum 10000mah {7} {}



Hauv kev ua lag luam, 4720 Txhob Txhuam Txhuam Cov Hluav Taws Xob yog siv los ntawm ntau cov chaw nyob hauv nruab nrab thiab yog li qhov tseeb ntawm VSD's 4720 lub cev muaj zog ntawm cov tsis muaj tseeb thiab kev teeb tsa kev teeb tsa kev teeb tsa?



Core Parameter sib piv

Cov Khoom Sib Piv	VSD 4720 Tsav	Lwm lub tuam txhab '4720
KV tus nqi	420	320
Siab tshaj plaws fais fab	3037W	1600W
Qhov siab tshaj plaws	99.7A	48A
Kev muaj zog loj	φ54.7 × 69.8 hli	φ50 × 65 hli (kwv yees li)
Qhov hnyav (suav nrog xaim)	336±3g	270g
Hlau Teeb	14AWG / 800mm	18AWG / 450mm (nquag)
Qib Kub Qib	H Qib (180 Qib)	Tsis muaj kev kawm (lub neej ntawd yog F Qib 155 degree)
Cov lus pom zoo	HQ15x7x3 / GF13xx9X3	18x6.1 / 18x5.5 (Txwv rau qis KV)
Muaj feemc	80A / 100A EC	Dav dav dav dua lossis sib npaug rau 60a esc



Cov ntsiab lus ntawm qhov sib txawv thiab qhov zoo

Lub zog siab dua: Peb 4720 lub cev muaj zog muaj lub zog siab tshaj plaws ntawm 3037W, uas yog li ob zaug ntawm cov khoom lag luam tseem ceeb, thiab yog tsim nyog tshwj xeeb rau cov khoom lag luam davhlau loj;



Ntau dua KV tus nqi, muaj zog teb: 420KV muab cov lus teb ceev ceev, haum rau kev hla lossis hnyav-thauj cov platform coj tawm;



Ntev thiab tuab xaim: 14



Qhov kev tswj hwm qhov kev tswj kub zoo: Nrog H-chav w-cleck, qhov kub yog tswj tsis pub dhau 92℃txawm nyob rau hauv tag nrho cov kev txwv;



Cov kws lij choj sib raug zoo yog cov muaj ntau yam ntxiv: Txhawb nqa 15x7x3, 132 × 6 {{{{8} yog qhov haum rau kev sib tw ntawm ntau lub davhlau platform.



Peb tsom mus rau txoj kev txhim kho thiab tsim cov khoom lag luam uas txhuam siab, tab sis kuj tseem muab kev txhawb nqa cov khoom lag luam zoo, tab sis kuj tseem muaj kev txhawb nqa rau ntiaj teb nolone {}}



Hoobkas zog thiab ntxiv cov thev naus laus zis

Nws muaj kaum tawm ntawm cov cua tsis siv neeg, sib dhos thiab siv cov kab ntau lawm, nrog ib xyoo ntau lawm muaj peev ntau ntawm ntau lab;



Tag nrho cov motors tau dhau qhov kev sim siab kub, thrust kuaj, ntsuas hluav taws xob haum, thiab txhawb nqa kev xeem thib peb-tog;



Cov khoom tsim pab pawg muaj cov kev paub ntau ntxiv hauv cov qauv dav hlau thiab cov txheej txheem tsav tsheb siv hluav taws xob raws li cov neeg siv khoom xav tau {}}}



Pa Flexible Kev Siv Peev Xwm

KV tus nqi, Ncej ntev, hlau ntev, hlau ntev, logo lo lo ntxhuav npo, thiab lwm yam} tuaj yeem raug kho tau raws li cov neeg siv khoom xav tau;



Muab cov kev ntsuas ntsuas thiab cov kev pom zoo rau cov kiv cua thiab esc kom txo cov nqi cov neeg siv kev sib tw;



Kev them nyiaj yug MOQ Customization thiab muab kev txhawb nqa hloov tau rau cov haujlwm tshiab lossis cov neeg siv khoom me me thiab nruab nrab {}}



Ib-Nres Kev Pabcuam

Muab cov txheej txheem txhawb nqa ua ke los ntawm cov piv txwv kuaj mob



Tuaj yeem pab cov neeg siv khoom nrog cov kiv cua hniav yoog, hluav taws xob kev hloov kho, kev tswj hwm cov chav sib haum, thiab lwm yam}



Rau OEM cov neeg yuav khoom, peb tuaj yeem muab cov ntim ntim tsis tau luam, cov khoom lag luam dawb, thiab kev txhawb nqa kev txhawb nqa {}}



Xaiv peb txhais tau tias xaiv ib tus khub txhim khu kev qha, txuag muaj lub cev muaj zog nrog keeb kwm yav dhau los .
