Brushed Coreless Tsav

Lub VSD Brushed Coreless Tsav yog ib qho kev ua haujlwm siab zoo hlau txhuam DC lub cev muaj zog tsim los rau cov ntawv thov uas nrhiav kev ua haujlwm zoo dua. Lub cev muaj zog siv cov txhuam hniav zoo nkauj, ua haujlwm siab Ndfeb hlau nplaum thiab cov lus qhia zoo siab lub zog enamelled hlau windings, featuring compact qauv thiab lub teeb yuag, muab kev ua haujlwm zoo thiab kev tswj xyuas meej. Tus qauv voltage ntau npog 3V, 6V, 12V thiab 24V, tsis muaj-load ceev yog mus txog 13000rpm, lub siab tshaj plaws efficiency yog 80%, lub ceev tshaj txhua yam teb lub sij hawm tsuas yog 10ms, thiab nws muaj peev xwm yooj yim tiv nrog qhov xav tau dynamic tej yam kev mob.



Lub teeb yuag tsim ntawm VSD Brushed Coreless Tsav ua rau nws yooj yim rau kev koom ua ke rau hauv ntau lub tshuab, thaum lub cev muaj zog tuaj yeem ua raws li cov neeg siv khoom xav tau, suav nrog voltage, ceev, bearing, txhuam, loj thiab interface. Tsis tas li ntawd, lub cev muaj zog kuj tseem tuaj yeem ua rau kev sib xyaw ua ke sib kis thiab encoder, ntxiv kev nthuav dav nws siv hauv kev tswj xyuas qhov tseeb thiab kev siv nyuaj.



VSD ib txwm muab cov khoom zoo ua ntej. Peb ua raws li kev tswj hwm nruj thiab kev tshuaj xyuas hauv cov txheej txheem tsim khoom kom ntseeg tau tias txhua lub cev muaj zog ua tau raws li cov qauv kev lag luam thiab cov neeg siv khoom xav tau. Peb lub Hoobkas tau nruab nrog cov cuab yeej ua haujlwm siab tshaj plaws, muaj pab pawg R & D ntawm ntau dua 30 tus neeg thiab ntau dua 500 tus neeg ua haujlwm hauv pem hauv ntej, nrog rau cov khoom tsim tawm txhua hnub ntau dua 200, 000 units, los muab cov neeg siv khoom thoob ntiaj teb nrog kev pabcuam ceev thiab txhim khu kev qha.



Tsis tas li ntawd, VSD muab cov kev pabcuam hloov kho tau yooj yim, suav nrog cov qauv CNC machining thiab pwm tsim, kom ntseeg tau tias cov khoom lag luam customized ua tau raws li cov neeg siv khoom xav tau hauv qhov tsos thiab kev ua tau zoo. Nrog ntau tshaj kaum xyoo ntawm kev lag luam txawv teb chaws thiab kev lag luam thoob ntiaj teb, VSD Brushed Coreless Motors tau txais kev ntseeg siab ntawm cov neeg siv khoom hauv tsev thiab txawv teb chaws. Los ntawm kev xaiv VSD, koj yuav tau txais kev ua haujlwm siab, txhim khu kev qha thiab hloov pauv lub cev muaj zog.





Txheem Voltage	3V	6V	12V	24V
Rated Ceev	8800rpm ua	10 400 rpm
Standard Tam sim no	0.89A	0.58A	0.37A	0.18A
Rated Torque	2.12mnm ua	2,42m wb	2,95m :ua	2,96m wb
Tsis-Load Speed	11000 rpm	13 000 rpm
Tsis-Load Tam sim no	65mA ua	30mA ua	30mA ua	10mA ua
Kev ua tau zoo tshaj plaws	76.70%	80.40%	75.40%	79.60%
Terminal Resistance	0.71Ω	2.14Ω	6.94Ω	27.91Ω
Torque tsis tu ncua	2.56 mNm/A	4.36 mNm/A	8.66 mNm/A	17.42 mNm/A
Mechanical Sijhawm	8.5ms ib	9,7ms ib	8.3ms ib	7,9ms ib
Rotor Inertia	0.78g·cm²	0 86g·cm²	0.90g·cm²	0 86g·cm²
Lub cev hnyav	24g
Lub suab nrov	Tsawg dua lossis sib npaug li 38 dB





Nrog nws cov qauv tsim thiab kev ua tau zoo, VSD 1722 brushed Brushed Coreless Tsav yog qhov zoo tagnrho rau kev siv nrog kev ua haujlwm siab, tsis tshua muaj suab nrov thiab siab torque. Cov hauv qab no yog cov yam ntxwv tseem ceeb ntawm lub cev muaj zog:



Kev ua haujlwm siab: Lub cev muaj zog siv cov txhuam hniav zoo nkauj, cov khoom siv hluav taws xob zoo heev, kom ntseeg tau tias kev ua haujlwm siab thiab kev ua haujlwm siab. Qhov siab tshaj plaws nyob rau hauv qhov sib txawv voltages yog: 76.7% (3V), 80.4% (6V), 75.4% (12V), 79.6% (24V), muab lub zog txuas ntxiv thiab txhim khu kev qha rau ntau lub tshuab.



Kev ua haujlwm du thiab nyob ntsiag to: lub cev muaj zog tsim kom zoo, suab nrov decibels Tsawg dua lossis sib npaug li 38, kom ntseeg tau tias nws nyob ntsiag to thaum ua haujlwm, haum rau cov suab nrov-sensitive thov scenarios.



High torque tso zis: Lub cev muaj zog muab lub zog siab tso zis, ntsuas ntawm: 2.12mNm (3V), 2.42mNm (6V), 2.95mNm (12V), 2.96mNm (24V), muaj peev xwm muab kev tswj xyuas meej thiab txhim kho lub zog rau lub cev .



Compact thiab lub teeb yuag: VSD Brushed Coreless Tsav yog compact thiab hnav, nrog lub cev nyhav ntawm tsuas yog 24g, haum rau qhov chaw txwv tsis pub siv thiab tuaj yeem yooj yim rau hauv ntau lub tshuab.



Lub neej ntev: Kev tsim qauv zoo thiab txheej txheem ua kom muaj kev ntseeg siab thiab ua haujlwm ntawm lub cev muaj zog, nrog rau lub neej ntev. Nws lub sijhawm teb txhua yam tsuas yog: 8.5ms (3V), 9.7ms (6V), 8.3ms (12V), 7.9ms (24V), kom ntseeg tau tias kev ua haujlwm tau zoo thiab cov lus teb ceev.



Customized yooj: Raws li kev thov sib txawv, VSD tuaj yeem muab kev ua haujlwm ntawm lub cev muaj zog, suav nrog qhov hluav taws xob, nrawm (tseem nrawm raws li tus qauv voltage: 8800rpm (3V), 10400rpm (6V, 12V, 24V)), qhov loj me, interface, thiab lwm yam. ua tau raws li ntau yam kev xav tau ntawm tus kheej.



Kev sib txuas sib txuas thiab kev xaiv encoder: Txhawm rau ua kom tau raws li qhov xav tau ntawm cov kev lag luam sib txawv, VSD Brushed Coreless Tsav kuj tseem tuaj yeem nruab nrog kev sib txuas lus thiab kev xaiv encoder los txhim kho lub cev muaj zog kev ua tau zoo thiab kev tswj xyuas qhov tseeb, ua kom cov txiaj ntsig zoo tshaj plaws nyob rau hauv high-precision scenarios.





Nrog nws qhov zoo ntawm kev ua haujlwm siab, ruaj khov, tsis tshua muaj suab nrov thiab siab torque, Brushed Coreless Motors tau siv dav hauv ntau qhov kev lag luam. Cov hauv qab no yog cov chaw siv tseem ceeb ntawm lub cev muaj zog:



Cov khoom siv kho mob: Txhuam Txhuam Coreless Tsav yog qhov tseem ceeb tshwj xeeb hauv kev siv cov khoom siv kho mob, tshwj xeeb tshaj yog nyob rau hauv cov khoom siv xws li cov twj tso kua mis thiab cov cuab yeej phais. Nws muaj peev xwm tswj tau meej thiab ruaj khov siab kom ntseeg tau tias cov cuab yeej kho mob tuaj yeem ua haujlwm zoo los xyuas kom cov neeg mob muaj kev nyab xeeb.



Cov khoom siv hauv tsev: Rau cov khoom siv hauv tsev me me, tshwj xeeb tshaj yog cov uas muaj suab nrov thiab kev ua haujlwm zoo, txhuam Coreless Motors muab cov kev daws teeb meem zoo tshaj plaws. Nws cov suab nrov qis thiab cov yam ntxwv ua haujlwm siab ua rau nws yog qhov kev xaiv zoo tshaj plaws rau cov khoom siv hauv tsev zoo thiab txhim kho cov neeg siv kev paub.



Kev lag luam automation: Hauv kev lag luam automation, brushed Coreless Motors yog dav siv nyob rau hauv sensors thiab automated mechanical khoom. Lub cev muaj zog ua haujlwm siab thiab siab torque tso tawm kom nws ua haujlwm ruaj khov hauv qhov chaw muaj kev lag luam, pab txhim kho kev tsim khoom thiab cov khoom raug.



Cov khoom siv tes tuav: Cov cuab yeej tuav tes xws li tshuab tattoo, uas yuav tsum tau muaj kev vibration qis, kev kub ceev thiab kev tswj xyuas meej, txhuam Coreless Motors muab kev txhawb zog zoo, txhim kho cov neeg siv kev paub thiab ua kom muaj kev ua haujlwm zoo thiab kev nyab xeeb.



Aerospace & Drones: Lub teeb yuag thiab kev ua haujlwm siab yog qhov tseem ceeb hauv aerospace & drone sector. Brushed Coreless Motors nrog lub zog siab thiab kev ua haujlwm siab tuaj yeem ua tau raws li cov cai nruj ntawm lub zog thiab kev tswj xyuas meej hauv cov haujlwm no, thiab tau siv dav hauv kev tsav dav hlau.



Tsis tas li ntawd, VSD brushed Coreless Tsav txhawb nqa DC voltage lossis PWM teeb liab tsav, tuaj yeem hloov kho rau ntau yam kev vibration thiab haptic tawm tswv yim scenarios, ntxiv nthuav nws daim ntawv thov ntau yam, kom tau raws li qhov xav tau ntawm cov khoom sib txawv.



Txawm hais tias nws yog nyob rau hauv kev kho mob, cov khoom siv hauv tsev, kev lag luam automation, los yog hauv cov khoom siv tes, aerospace thiab unmanned aerial tsheb, brushed Coreless Motor muab cov kev daws teeb meem zoo thiab txhim khu kev qha rau ntau qhov kev lag luam nrog nws cov kev ua tau zoo heev thiab dav adaptability.





VSD Co., Ltd. yog lub chaw tsim khoom tshwj xeeb los muab cov khoom lag luam zoo micromotor thiab cov kev pabcuam rau cov neeg siv khoom thoob ntiaj teb. Nrog ntau tshaj kaum xyoo ntawm kev lag luam kev lag luam, peb tau sau cov nplua nuj kev muaj zog hauv kev txhim kho, tsim khoom thiab kev pabcuam kev cai ntawm brushed Coreless Motors. Peb pab pawg tseem ceeb muaj cov kws tshaj lij kev lag luam xws li Tus Thawj Saib Xyuas Kev Lag Luam, Tus Lwm Thawj Coj General, Tus Lwm Thawj Coj General ntawm Engineering thiab Chief Engineer, uas coj VSD mus txuas ntxiv txhawb cov khoom lag luam tshiab thiab kev tswj xyuas kom zoo kom ntseeg tau tias txhua lub cev muaj zog ua tau raws li cov qauv thoob ntiaj teb.



Nrog nws tus kheej lub Hoobkas thiab cov kab ntau lawm, VSD txiav tawm cov neeg nruab nrab txuas thiab ncaj qha muab cov khoom zoo siab brushed Coreless Motors rau cov neeg siv khoom. Los ntawm cov khoom siv ncaj qha los ntawm cov tuam ntxhab, peb tuaj yeem muab cov khoom lag luam nrog cov nqi siab dua, thiab ua kom cov khoom xa tuaj sai sai kom tau raws li cov neeg siv khoom raws sijhawm.



VSD Co., Ltd. ib txwm ua raws li cov qauv zoo thiab tau dhau ISO, CE thiab lwm yam ntawv pov thawj thoob ntiaj teb. Peb cov txheej txheem tsim khoom yog nruab nrog cov cuab yeej ntsuas qib siab, kev ua haujlwm nruj ntawm kev tswj hwm kev ua haujlwm zoo, kom ntseeg tau tias txhua tus txhuam Coreless Tsav ua tau raws li qhov yuav tsum tau ua kom zoo, thiab tuaj yeem ua haujlwm ruaj khov hauv ntau yam kev lag luam thiab cov ntawv thov.



VSD tseem ceeb heev rau kev ntim khoom thiab kev thauj mus los ntawm cov khoom. Peb siv cov ntaub ntawv pov thawj poob siab los qhwv cov motors, uas txo cov kev poob siab thiab kev co thaum lub sij hawm thauj mus los thiab zoo tiv thaiv cov khoom los ntawm kev puas tsuaj. Txhua lub thawv muaj peev xwm tuav tau 60 daim ntawm kev poob siab-pov thawj ua npuas ncauj, yoog raws li qhov xav tau ntawm cov qauv sib txawv ntawm lub cev muaj zog thiab qhov ntau thiab tsawg, kom ntseeg tau tias cov khoom ncav cuag cov neeg siv khoom txhais tes zoo.



Peb muab ntau txoj kev xa khoom yooj yim nrog rau DHL, UPS, FedEx, TNT, EMS, thiab kev pabcuam thauj khoom hiav txwv kom ntseeg tau tias cov khoom tuaj yeem xa tau sai thiab nyab xeeb thoob ntiaj teb. Txawm hais tias nws yog ib pob me me los yog cov khoom xa tuaj loj, peb muaj kev txhim khu kev qha shipping kom tau raws li koj xav tau.
