Micro Coreless Tsav

Micro Coreless lub cev muaj zog yog qhov ua tau zoo DC lub cev muaj zog siv dav hauv kev lag luam xws li cov cuab yeej siv hluav taws xob thiab cov cuab yeej precision. VSD's Micro Coreless Tsav npog ob series: brushed DC thiab brushless DC, featuring zoo heev kev ua tau zoo thiab kev ntseeg tau. Nws siv ob lub pob bearings, cov ntaub ntawv zoo, thiab cov txheej txheem tsim khoom kom ntseeg tau tias kev ua haujlwm ruaj khov thiab lub neej ntev, thaum txhawb kev ua haujlwm zoo ntawm DC voltages ntawm 12V, 24V, thiab 36V.



Piv rau hlau-core motors nrog tib lub zog, Micro Coreless Tsav txo qhov hnyav thiab loj los ntawm 1/3 txog 1/2. Nws tsis tshua muaj inertia tsim ua kom nrawm nrawm thiab nrawm, nrog lub sijhawm teb tsawg li 10 milliseconds. Tsis tas li ntawd, lub cev muaj zog tuaj yeem ua ke nrog high-precision encoders lossis lub tshuab tsav kom ua tiav qhov kev tswj hwm ntawm kev ceev thiab txoj haujlwm, ua rau nws tsim nyog rau cov khoom siv me me uas xav tau lub zog siab thiab lub zog siab.



VSD's Micro Coreless Tsav txhawb nqa ntau yam kev xaiv, suav nrog qhov loj me, tso zis ncej, ceev, qhov hluav taws xob, cov hlau lead, thiab cov hlau lead hlau terminals. Nws kuj tseem tuaj yeem ua ke nrog cov khoom siv xws li tsav tsheb, encoders, thiab planetary gearboxes kom tau raws li qhov xav tau ntawm cov ntawv thov sib txawv. Piv txwv li, 6mm thiab 10mm micro motors yog qhov zoo tagnrho rau qhov chaw txwv tsis pub siv, thaum lub cev muaj zog tsis muaj zog thiab cov qauv sib nqus zoo dua rau cov hom phiaj tshwj xeeb.



Raws li cov kws tshaj lij kev tsim khoom siv lub cev muaj zog, VSD ua kom cov khoom sib xws thiab ua tau zoo los ntawm cov kab ntau lawm niaj hnub thiab kev tswj xyuas nruj. Nrog rau tus qauv xa khoom ncaj qha los ntawm lub Hoobkas, VSD muab cov neeg siv khoom sib tw nqi, txhawb nqa ntau txoj kev xa khoom, thiab muab kev pabcuam kev lis kev cai thoob ntiaj teb kom ntseeg tau raws sijhawm. Lub voj voog tus qauv xa khoom yog 15 txog 40 hnub, nrog cov kev xaiv nrawm nrawm kom tau raws li qhov xav tau ceev.





VSD - 3242 Micro Coreless Tsav

Lub VSD - 3242 Micro Coreless Tsav yog ib qho kev ua tau zoo ntawm kev ua haujlwm siab compact tsav tsim los rau cov ntawv thov nrog qhov chaw txwv thiab siab precision thiab kev ua haujlwm tau zoo. Nrog rau txoj kab uas hla ntawm kwv yees li 32 hli thiab qhov ntev ntawm 42 hli, lub cev muaj zog no txhawb nqa qhov voltage xws li 6V thiab 12V, ua tiav kev ua haujlwm siab txog 80%. Nws yog txawm peem rau nrog high-precision pob bearings los xyuas kom meej lub sij hawm ruaj khov ua hauj lwm. Txawm hais tias nws qhov loj me, nws cov peev txheej siab ceev cov qauv tsim hluav taws xob muab cov zis muaj zog.



Lub cev muaj zog no muaj cov qauv tsis txhuam, muab cov suab nrov qis thiab kev co thaum lub sijhawm ua haujlwm, ua rau nws yog qhov kev xaiv zoo tshaj plaws rau cov xwm txheej uas xav tau kev ua haujlwm ntsiag to thiab du. Tsis tas li ntawd, nws txhawb high-precision encoders los yog tsav lub tshuab kom ua tiav kev tswj ceev thiab txoj hauj lwm, ua rau nws tsim nyog rau cov teb xws li automation khoom thiab precision instruments.



VSD - 3242 Micro Coreless Tsav yog dav siv hauv kev lag luam xws li cov cuab yeej kho mob thiab cov neeg hlau. Hauv cov cuab yeej phais thiab cov cuab yeej kuaj mob, nws txhim kho cov neeg siv kev paub nrog kev ua haujlwm siab thiab tsis tshua muaj suab nrov. Nyob rau hauv precision robotics thiab automated los ua ke systems, nws saj zawg zog tswj kev muaj peev xwm ua kom muaj txiaj ntsig zoo ntawm kev ua haujlwm nyuaj. Lub VSD - 3242 zoo kawg nkaus sib txuas ua ke me me thiab kev ua haujlwm tshwj xeeb, ua rau nws yog qhov kev xaiv zoo tshaj plaws rau kev siv thev naus laus zis tshiab.



VSD - 3242 Coreless Tsav Tsim

VSD - 3260 Micro Coreless Tsav

Lub VSD - 3260 Micro Coreless Tsav yog cov khoom lag luam uas muaj kev ua haujlwm siab brushless tsav uas sib txuas cov qauv tsim nrog kev ua tau zoo tshwj xeeb, ua rau nws siv dav hauv cov teb xav tau kev ua haujlwm siab, precision, thiab kev ntseeg tau. Nrog rau txoj kab uas hla ntawm 32mm thiab ntev ntawm 60mm, lub cev muaj zog txhawb nqa qhov ntsuas hluav taws xob ntau ntawm 16V txog 36V, muab qhov tsis muaj qhov nrawm ntawm kwv yees li 12,700 txog 13,300 rpm, ntsuas lub zog ntawm 58.7W txog 61.5W, thiab ntsuas lub zog. txog li 45 mN·m, ua tiav qib ntawm 85% mus rau 95%.



Featuring ib tug brushless tsim, lub cev muaj zog txo hnav thiab ho txuas nws lub neej kev pab cuam, ua rau nws zoo tagnrho rau high-frequency daim ntawv thov scenarios. Nws cov qauv tsis tseem ceeb ntxiv txo qis inertia, ua kom cov lus teb sai thiab kev tswj xyuas siab. Tsis tas li ntawd, lub cev muaj zog boasts lub zog siab ntom ntom thiab kev tiv thaiv zoo heev ntawm kev cuam tshuam, nrog cov suab nrov tsis muaj zog thiab tsis muaj hluav taws xob.



Vim nws lub teeb yuag, kev ua haujlwm siab, thiab cov yam ntxwv siab ceev, VSD - 3260 Micro Coreless Tsav yog dav siv nyob rau hauv drone propulsion systems thiab RC qauv, xa lub zog muaj zog rau cov chaw taws teeb tswj tsheb thiab dav hlau. Tsis tas li ntawd, nws ua lub luag haujlwm tseem ceeb hauv cov khoom siv kho mob, muab kev tswj xyuas meej thiab tsis muaj suab nrov kom tau raws li qhov xav tau ntawm kev ua haujlwm nyuaj. VSD - 3260 piv txwv txog kev tsim kho tshiab thiab tsim nyog rau ntau yam kev thov ib puag ncig.



VSD - 3260 Coreless Tsav Tsim

VSD - 3557 Micro Coreless Tsav

VSD {{0}} Micro Coreless Lub cev muaj zog sawv tawm rau nws qhov kev ua haujlwm siab thiab tsim qauv, ua rau nws yog qhov kev xaiv zoo tshaj plaws rau ntau yam kev siv. Lub cev muaj zog no txhawb nqa qhov ntsuas hluav taws xob ntau ntawm 12V txog 32V, nrog kev ntsuas nrawm ntawm 417 rpm, ntsuas tam sim no ntau yam ntawm 0.28A txog 0.7A, lub ncov torque ntawm 15 mN·m, thiab lub zog ua haujlwm ntawm nce. rau 82%. Nws qhov loj me me thiab 6: 1 iav piv, ua ke nrog qhov hnyav ntawm kwv yees li 5.25 phaus, ua rau nws tshwj xeeb tshaj yog haum rau qhov xwm txheej ntawm qhov chaw.



Nrog rau qhov qis-inertia tsim, lub cev muaj zog xa cov lus teb sai, lub sijhawm siv tshuab tsis tu ncua raws li qis li 10 milliseconds, thiab qis pib voltage thiab tam sim no cov yam ntxwv, zoo txuas ntxiv roj teeb lub neej. Nws qhov zoo ntawm lub suab qis thiab kev vibration qis ua rau nws zoo tagnrho rau cov ntawv thov uas yuav tsum tau ua haujlwm ntsiag to. Tsis tas li ntawd, lub siab torque thiab lub neej ntev yog kev txhawb nqa los ntawm cov hlau ruaj khov thiab lubrication ruaj khov, ua kom muaj kev ruaj ntseg ntev.



Hauv kev kho mob, VSD - 3557 Micro Coreless Tsav yog dav siv hauv cov twj tso kua mis insulin, cov cuab yeej phais, thiab lub tshuab ua pa, txhim kho cov cuab yeej ua haujlwm nrog lub suab qis thiab kev tswj xyuas meej. Nyob rau hauv kev lag luam automation, nws yog qhov zoo-tsim rau precision motion Cheebtsam hauv automated ntau lawm kab. Hauv cov neeg siv khoom siv hluav taws xob thiab cov khoom siv nqa tau yooj yim, xws li khoos phis tawj, tshuab luam ntawv inkjet, thiab moos, lub cev muaj zog no muab cov kev daws teeb meem zoo ua tsaug rau nws cov qauv tsim thiab kev ua haujlwm siab.



VSD - 3557 Coreless Tsav Tsim

VSD - 3571 Micro Coreless Tsav

VSD - 3571 Micro Coreless Tsav yog qhov kev xaiv zoo tshaj plaws rau kev lag luam thiab kev siv thev naus laus zis, muab kev ua haujlwm siab thiab txhim khu kev qha. Nrog rau sab nraud txoj kab uas hla ntawm 35 hli, qhov ntev ntawm 71 hli, thiab qhov hnyav ntawm tsuas yog 220g, lub cev muaj zog no ua haujlwm ntawm qhov ntsuas hluav taws xob ntawm 24V thiab xa cov tsis muaj kev thauj khoom ceev txog li 11, 000 rpm. Nws ua tiav lub zog siab tshaj plaws ntawm 50W nrog kev ua haujlwm txog li 75.3%. Lub coreless tsim ho txo ​​eddy tam sim no poob, txhim kho tag nrho efficiency thaum txo qis inertia rotational. Qhov no ua kom cov lus teb sai, nrog lub sijhawm siv tshuab tsis tu ncua tsawg dua 10 milliseconds.



Lub cev muaj zog ua haujlwm zoo nrog lub suab qis, ua rau nws zoo tagnrho rau cov ntawv thov kev ua haujlwm ntsiag to. Ua nrog cov ntaub ntawv zoo thiab cov txheej txheem tsim khoom, VSD - 3571 boasts lub neej ua haujlwm ntev. Nws lub zog siab ceev ua rau nws tshwj xeeb zoo rau cov ntawv thov uas qhov chaw txwv, tab sis kev ua tau zoo yuav tsum nruj.



Hauv kev lag luam automation, lub cev muaj zog no tau siv dav hauv cov khoom siv xws li tshuab winding, tshuab luam ntawv, binders, thiab tshuab txiav. Hauv robotics, nws yog qhov zoo tagnrho rau cov pob qij txha thiab cov tsav tsheb. Tsis tas li ntawd, hauv cov cuab yeej siv hluav taws xob zoo li lub tshuab hluav taws xob thiab cov cuab yeej xyaum, VSD - 3571 sawv tawm nrog nws cov txiaj ntsig zoo thiab kev ua haujlwm ruaj khov.



VSD - 3557 Coreless Tsav Tsim





Micro coreless motors, nrog rau lawv cov kev ua tau zoo tshwj xeeb thiab tsim tshiab, ua haujlwm zoo tshaj plaws rau kev daws teeb meem rau ntau yam khoom siv. Featuring ib tug tshwj xeeb coreless qauv, cov motors tshem tawm qhov yuav tsum tau rau ib tug hlau core, hauv paus ntsiab lus txo eddy tam sim no losses thiab ua kom tiav tag nrho cov txiaj ntsig ntawm 70% mus rau 90%, teeb tsa tus qauv tshiab rau kev ua kom zoo zog.



Cov motors no muaj lub zog siab ceev, xa tawm lub zog muaj zog txawm tias lawv qhov loj me, ua rau lawv zoo kawg nkaus rau kev siv nrog qhov hnyav hnyav thiab qhov chaw txwv. Tsis tas li ntawd, qhov pib qis qis thiab cov qauv tsim tam sim no txhim kho lub zog ua haujlwm tau zoo, txuas ntxiv lub roj teeb lub neej ntawm cov khoom siv txawb thiab cov khoom siv txawb, yog li nthuav lawv daim ntawv thov muaj peev xwm.



Lub siab torque thiab ntev lifespan tsim ua rau micro coreless motors zoo heev. Ua ke nrog cov iav steel thiab cov roj nplua nyeem ruaj khov, lawv muaj kev ua tau zoo txawm tias nyob rau hauv cov xwm txheej hnyav. Cov yam ntxwv qis-inertia ua rau cov lus teb sai, nrog lub sijhawm siv tshuab tsis tu ncua ntawm tsawg dua 28 milliseconds, thiab rau qee yam khoom, txawm tias qis dua 10 milliseconds, muab kev tswj tsis tau zoo rau cov cuab yeej xav tau ceev ceev.



Cov motors no txhawb DC voltage los yog PWM teeb liab tsav, ua rau lawv haum rau ntau yam kev co thiab haptic tawm tswv yim scenarios, xa ib tug intuitive neeg siv kev paub. Los ntawm cov kev xaiv modular, lawv tuaj yeem ua ke nrog lub ntiaj teb gearboxes lossis sib nqus encoders kom tau raws li kev tswj hwm kev xav tau ntawm cov ntawv thov nyuaj.



Txawm nyob rau hauv high-efficiency industrial chaw los yog nyob rau hauv precision-tseem ceeb cov cuab yeej kho mob, micro coreless motors qhia unmatched zoo. Lawv txoj kev tsim kho tshiab thiab kev ua tau zoo txhim khu kev qha yog tsav kev txhim kho thev naus laus zis, muab cov kev daws teeb meem zoo dua thiab hloov pauv thoob plaws ntau yam kev lag luam.





Micro coreless motors, nrog rau lawv qhov kev ua tau zoo tshwj xeeb thiab ntau yam kev thov, yog qhov kev xaiv zoo tshaj plaws rau kev hloov kho khoom siv thoob plaws kev lag luam. Lawv cov qauv tsim tshwj xeeb tsis yog tsuas yog lub teeb yuag thiab compact, tab sis kuj muab siab precision, efficiency, thiab tsis tshua muaj suab nrov tswj, ua tau raws li qhov yuav tsum tau ua ntawm cov cuab yeej siv niaj hnub no rau kev ua haujlwm thiab kev txav mus los.



Hauv kev lag luam ntawm cov khoom siv kho mob, micro coreless motors tau siv dav hauv cov cuab yeej phais thiab cov cuab yeej kuaj mob, muab kev ua haujlwm zoo heev thiab tsis tshua muaj suab nrov, tsim kom muaj kev ua haujlwm ntsiag to thiab muaj txiaj ntsig zoo rau cov kws kho mob. Hauv cov neeg hlau, cov motors no, los ntawm kev tswj cov lus hloov tau yooj yim, dhau los ua qhov kev xaiv zoo tshaj plaws rau kev sib koom ua ke ntawm cov neeg hlau thiab kev tswj lub log, ua tau zoo hauv cov tshuab sib dhos.



Nyob rau hauv aerospace sector, micro coreless motors, nrog rau lawv cov high-precision tsav tsheb muaj peev xwm, yog dav siv nyob rau hauv drones thiab qauv aircraft, ua kom yooj yim khiav lag luam ntawm high-kev ua tau zoo aircraft. Ib txhij, nyob rau hauv kev lag luam automation, cov motors, raws li ib tug tsav tsheb qhov chaw, txhawb cov lus tsa suab tswj ntawm precision machinery thiab automated ntau lawm kab, kev txhim kho ntau lawm efficiency thiab kev cia siab rau.



Tsis tas li ntawd, micro coreless motors qhia lawv tus nqi tshwj xeeb hauv lub neej txhua hnub, xws li hauv cov tshuab hluav taws xob, cov txhuam hniav hluav taws xob, thiab lwm yam khoom siv hluav taws xob me me, tso siab rau lawv cov khoom siv hluav taws xob ruaj khov thiab muaj txiaj ntsig zoo. Hauv cov neeg siv khoom siv hluav taws xob thiab cov khoom siv nqa tau yooj yim, xws li tshuab luam ntawv inkjet, cov cuab yeej siv computer, thiab cov moos, lawv siv lawv cov qauv tsim kom ua tiav kev ua haujlwm tau zoo thiab siv qhov chaw zoo.



Los ntawm cov khoom siv high-precision muaj rau cov neeg siv khoom siv hauv cov khoom lag luam, micro coreless motors, nrog lawv cov kev ua tau zoo thiab ntau yam, tau dhau los ua lub zog tseem ceeb rau cov cuab yeej siv niaj hnub no, txhawb nqa ntau yam kev lag luam mus rau lub neej yav tom ntej.



Micro coreless motors, nrog rau lawv cov kev ua tau zoo, lub teeb yuag tsim, thiab ntau yam, yog lub zog tsav zoo tshaj plaws rau cov khoom siv niaj hnub precision. Raws li cov kws tshaj lij cov chaw tsim khoom thiab xa tawm ntawm micro coreless motors, VSD Co., Ltd., tau txais kev ntseeg siab thoob ntiaj teb nrog cov thev naus laus zis thiab cov khoom lag luam txhim khu kev qha.



VSD tsom ntsoov rau kev muab cov tshuab zoo micro coreless, mob siab rau ua kom tau raws li cov neeg siv khoom xav tau rau cov nqi tsim nyog thiab cov kev daws teeb meem zoo. Peb cov motors tsim nyog rau ntau yam, suav nrog cov khoom siv kho mob, neeg hlau, cov khoom siv hluav taws xob, thiab kev lag luam automation, muab cov txiaj ntsig zoo xws li kev ua haujlwm siab, siab zog ceev, thiab cov lus teb ceev, xa cov kev txhim kho rau cov cuab yeej ua haujlwm.



Lub tuam txhab muaj ib pab neeg ntawm kev paub txog kev tswj thiab engineering kws txawj, tsom rau cov khoom innovation thiab kev tswj kom zoo. Peb muab cov kev pabcuam OEM thiab ODM hloov tau, tso cai rau cov khoom tsim kho kom haum raws li cov neeg siv khoom tshwj xeeb. VSD's micro coreless motors tau lees paub los ntawm cov qauv thoob ntiaj teb, xws li ISO thiab CE, ua kom ntseeg tau zoo thiab muaj kev ntseeg siab.



Nyob rau hauv cov nqe lus ntawm kev tsim, VSD tau txais kev siv cov cuab yeej ua haujlwm siab tshaj plaws, suav nrog cov tshuab tsis siv neeg brushless tsis siv neeg winding, laser tsis siv neeg ntsuas tshuab, thiab ntsuas tshuab, ua tiav cov khoom tsim tau zoo thiab zoo ib yam. Lub tuam txhab tseem tau nruab nrog ntau yam kev ntsuas kev ntsuas siab, xws li torque testers, kev ntsuas kev ua tau zoo, thiab kev vibration testers, kom ntseeg tau tias txhua lub cev muaj zog tau kuaj xyuas ua ntej tawm hauv lub hoobkas.



Raws li Tuam Tshoj tus thawj coj micro coreless lub cev muaj zog exporter, VSD muab kev txhawb nqa logistics, muab ntau yam kev xaiv kev thauj mus los thiab ua tiav cov kev pabcuam kev lis kev cai, kom ntseeg tau tias cov khoom xa khoom zoo thoob ntiaj teb. Txawm hais tias koj xav tau cov khoom lag luam zoo lossis cov kev daws teeb meem tsav tsheb, VSD tau npaj los muab kev txhawb nqa dav.
