D-shaft Micro Dc Iav Tsav
Sab nraud txoj kab uas hla: 12mm,
Ntev: 26mm,
Ncej taub: 3mm;
Rated Voltage: DC 2.4V, 3V, 6V, 12V, 24V;
Rotation Direction: CW & CCW
Dav siv dav hauv kev kho mob, kev zoo nkauj, kev saib xyuas kev noj qab haus huv niam thiab menyuam, tsev ntse, drones, tsheb, chaw ua haujlwm, qauv dav hlau, qauv khoom ua si, cov cuab yeej hluav taws xob, robots thiab lwm yam. Peb muaj 15 xyoo ntawm kev paub nyob rau hauv micro-motor ntau lawm thiab kev loj hlob, muab cov neeg muas zaub nrog saj zawg zog thiab kev customized kev pab cuam.
Hauj lwm lawm
N20 D-shaft Micro Dc Gear Tsav yog ua los ntawm cov hlau iav thiab tooj liab liab. Cov tooj liab coil muaj zog conductivity thiab tsis tshua muaj hluav taws xob tiam, uas ua rau lub cev muaj zog tso zis ruaj khov. Qhov ceev tuaj yeem hloov kho raws li qhov xav tau: 16RPM, 27RPM, 53RPM, 68RPM, 136RPM, 381RPM; kev ua haujlwm zoo, ruaj khov, tsis yooj yim rau hnav; nrog lub teeb yuag, siab torque, qis ceev, lub neej ntev thiab tsis tshua muaj suab nrov, ruaj khov kev ua tau zoo thiab lwm yam ntxwv, haum rau hauv cov khoom ua si ntse, simulation robots, hluav taws xob locks, ntse tsev, kev kho mob, kev lag luam thiab lwm yam kev lag luam, muaj kev phem cov neeg muas zaub uas customize designs raws li cov neeg xav tau kev pab. Yog tias koj xav tau kev sib txuam encoders, lub thawv iav, thiab cov tsav tsheb, thov hu rau peb.
Tuam txhab Highlights
Txheej txheem cej luam
Warranty | 3 lub hlis - 1 xyoo |
Qhov Chaw Keeb Kwm | Shenzhen, Suav teb |
Hom Lub Npe | Vshida |
Qauv nab npawb | VSD-GBLN20 |
Kev siv | Cov khoom ua si ntse, simulation robots, hluav taws xob xauv, ntse hauv tsev, kho mob, muaj, ntse tsheb, neeg hlau, koob yees duab, thiab lwm yam. |
Hom | Lub cev muaj zog |
Qhov hnyav | TBD (qhov sib txawv qhov hnyav sib txawv) |
Cheebtsam | Diversifed |
Kev tsim kho | Permanent Magnet |
Kev sib hloov | Txhuam txhuam / txhuam |
Tiv thaiv Feature | Customized (Waterproof, fireproof, Fully enclosed) |
Kev ua tau zoo | 90 feem pua |
Cov kabmob | Pob Bearing |
| Hom Shast | D-shaft |
Rated ceev | 6-4000 (rpm) |
Rated Voltage | 12 (V) |
Pib tam sim no | 10 mA |
| Qhov ntev | 12 * 25 hli |
Cov nqe lus them nqi | 30 feem pua ua ntej, 70 feem pua tshuav |
Daim ntawv pov thawj | TIAB SA 16949 |
Customized | Txais |
Product Description
Kev tshawb fawb muaj zog thiab kev tsim muaj peev xwm, tsim ntau yam tshiab motors nyob rau hauv nruab nrab ntawm ib lub hlis kom tau raws li cov neeg siv khoom customization xav tau.
Lub cev muaj zog Parameter
VOLTAGE | TSIS PUB | NTAWM MAXIMUM EFFICIENCY | Pib | |||||
NOMINAL V | HLUB r / min | Tam sim no A | HLUB r / min | Tam sim no A | TORQUE mN.m | OUTPUT W | TORQUE mN.m | Tam sim no A |
6 | 100 | 0.15 | 65 | 0.029 | 5.62 | 1 | 11.5 | 0.35 |
Khoom Loj
Customizing khoom:Output ncej, Lead hlau, Connector, Mounting qhov, Ceev
Performance Curve
Cov ntsiab lus saum toj no tsuas yog siv rau kev siv xwb; cov ncauj lus kom ntxaws tsis ntawm N20 iav lub cev muaj zog tuaj yeem hloov pauv.
Khoom Paub meej
| 100 feem pua qhov tseeb duab |
|
Rotor: Ntshiab tooj liab hlau winding, high-zoo hlau core, nrog tsawg zog poob, tsis tshua muaj tam sim no tsis kam thiab kub tsis kam. | Kawg cap: Ua kom sov dissipation, txhim kho lub cev muaj zog rotor, ua kom lub neej ntev ntawm cov khoom, thiab xaiv cov khoom siv zoo. | |
| 100 feem pua qhov tseeb duab |
|
Cov kabmob: Xaiv cov kabmob uas muaj npe nrov, thiab xaiv cov pob bearings lossis roj-impregnated bearings raws li cov neeg siv khoom xav tau. | Chassis: Xaiv cov khoom uas muaj xeb, corrosion, thiab hnav resistant thiab muaj lub neej ntev. |
Motor piav qhia
1. Parameters - Rated Voltage: DC 12V; Ceev: 1000RPM; Qauv: GBLN20; Lub cev muaj zog: 15 x 12 x 25 mm (L * W * H); Iav Loj: 8.9 x 11.9 x 9.9 mm; Rotation Direction: CW&CCW;
2 Nta - Cov log tuaj yeem yooj yim mounted ntawm lub cav tso zis ncej, nrog cov yam ntxwv zoo heev thiab ruaj khov
3 Kev Ua Haujlwm - D-shaft Micro Dc Gear Tsav muaj lub zog siv hluav taws xob tsawg thiab suab nrov tsawg. Hloov cov khoom seem yuav muab koj cov khoom siv hluav taws xob thiab cov khoom siv kuaj pom tshiab. Cov kabmob zoo thiab kev pabcuam lub neej ntawm lub iav lub cev muaj zog tau txhim kho thiab ruaj khov heev
4 Qhov Zoo - Cov me me DC geared lub cev muaj zog yog qhov me me thiab lub teeb hauv qhov hnyav, thiab lub log tuaj yeem yooj yim ntsia tau rau ntawm qhov tso zis ncej ntawm lub cev muaj zog lossis nyoob hoom qav taub.
5 APPLICATIONS - Motors rau DIY RC kev nyiam ua, tsheb, drones, dav hlau, thiab lwm yam, me me gearbox motors, zoo hloov rau xeb lossis puas DC iav motors ntawm cov cav tov.
6. Muab kev pabcuam zoo tom qab muag, OEM & ODM kev pabcuam, kev pabcuam customized, thiab lwm yam.
Lub tuam txhab muaj zog
Peb lub tuam txhab muaj kev tsim khoom thiab kev tshawb fawb thiab kev txhim kho cov cuab yeej thiab cov kev tswj hwm kev tsim khoom siab heev, coj los ua ke ntau tus neeg ua haujlwm siab thiab tswj cov txuj ci hauv kev lag luam tsav tsheb, thiab muaj cov khoom lag luam muaj zog thiab kev tsim khoom. Tau dhau ISO 9001: 2015 kev tswj hwm qhov system ntawv pov thawj thiab
IATF16949: 2016 kev tswj xyuas qhov system ntawv pov thawj. Tam sim no, muaj ntau tshaj 500 tus neeg ua haujlwm ua haujlwm hauv ntej, ntau tshaj 40 cov kab ntau lawm, thiab ntau tshaj 300 cov khoom siv automation kom tau raws li koj qhov kev txiav txim loj.
Daim ntawv pov thawj khoom
Ib txhia ntawm peb cov neeg koom tes
Peb zoo siab ua haujlwm nrog koj hauv Suav teb ua tus khub mus sij hawm ntev. Txij li lub sijhawm ntev dhau los, peb tau cog lus los muab cov khoom lag luam nyob sab Europe thiab Asmeskas nrog lub zog siab DC iav motors.
Vim li cas thiaj xaiv peb?
Daim ntawv thov
Thauj Ntim
Ua npuas ncauj packing uas yog shockproof; tsim nyog thawv loj. Thov hu rau peb ua ntej yog tias koj xav tau kev pabcuam tshwj xeeb.
Kev Them Nyiaj & Xa
D-shaft Micro Dc Iav Tsav Luv Taw Qhia
N20 geared lub cev muaj zog yog cov khoom siv lub cev muaj zog, feem ntau yog siv rau hauv cov ntawv luam ntawv, daim ntawv lo strippers, tshuab luam ntawv barcode, neeg hlau, hluav taws xob qhov rooj xauv, tshuab luam ntawv, hluav taws xob saib, khoom siv zoo nkauj, zaub sawv, txee, vending machine thiab lwm yam.
Parameters ntawm geared motor yog raws li nram no:
Lub hwj chim: 3V 4.5V 6V 12V
Ceev: 3rpm ~ 1000rpm
Torque: Max 7 kg.cm
Loj: 12 * 10 * 25mm
Sab nraud txoj kab uas hla ntawm ncej: 3 hli (qhov ntev ntawm lub ncej tuaj yeem tsim raws li cov neeg siv khoom xav tau)
Cov zis ncej tuaj yeem ua rau hauv M3 xov, M4 xov
12 * 10mm miniature precision reducer.
Kev txo qis: 1/3, 1/5, 1/10, 1/30, 1/50, 1/63, 1/100, 1/150, 1/210, 1/250, 1/298, 1/370 , 1/380, 1/1000
Customized designs tuaj yeem ua raws li cov neeg siv khoom xav tau. Yog tias koj muaj lwm yam kev xav tau, thov hu rau peb, thiab peb yuav teb koj cov lus nug hauv online 24 teev hauv ib hnub, tos ntsoov rau koj cov lus nug.
